F17 FORMPLY

CAMEL FORMPLY has been manufactured at our plant in China,for in excess of 15 years and has been used successfully in the Asia Australia and New Zealand.
CAMEL FORMPLY resists dilute acids and alkalines which increases the number of uses that is obtained when used with concrete.
CAMEL FORMPLY surface is very smooth which transmits into the finish of the concrete.

Interview share

Product Details:

 BRAND NAME CAMEL-PLY
 SIZE
 1200 x 1800; 1200 × 2400mm
 GLUE
 Phenolic W.B.P Glue
 FILM Dynea Brown/Black Film
 CORE Eucalyptus
 THICKNESS 17mm
 THICKNESS TOLERANCE 0.2/0.5mm
KEY PROCESSINGTwo Times Hot-Press & Two Times Sanding
 USING TIMES 30~40 Times
CERTIFICATE CE; FCS; ISO 9001; AS6669.


AS 6669 is a quality standard for non-structural and structural film faced plywood used in the Australia and New Zealand building industry. The standard specifies requirements for the manufacture, grading, finishing, and branding of plywood used specifically in formwork, with a maximum length of 3100mm and width of 1500mm, intended to meet off-form surface finish requirements of Classes2, 3, 4 and 5 as specified in AS3610.1. Equivalent standards are AS 6669, AS 6669-2007, AS 6669:2016.



The typical size of an F17 formply is 1800*1200*17mm and 2400*1200*17mm. Glued with phenolic A-bond to meet the structural grade. Almost all formply has a black overlay.

Technical Requirement of AS 6669

F17 Stress Grade

The structural formply is generally sold as a graded product. F17 is the stress grade of plywood. Besides F17, there are also F14, F8, F11, F14, F22, F27 stress grade. The stress grades are also used for bracing plywood and sheathing plywood of AS/NZS 2269 standard.

AS/NZS 2269 is a standard for structural plywood in both Australia and New Zealand. AS 6669 is a standard for formwork plywood in Australia only. Even though the New Zealand standard committee didn’t participate in AS 6669, its market still recognizes this standard.

If two plywood has the same construction, then the higher stress grade plywood is stronger than lower stress grade plywood. Because stiffness and strength are a combination of the F-grade and the construction, if two plywood is different in structure, F17 is not necessarily better than F14 plywood.

Outer Veneer Grades

F, C, and D grade is the veneer quality of the face and back veneers which is beneath the surface overlay film.

Film Surface Quality Grades

Classes 2, 3, 4 and 5. AS 3610.1 defines classes of off-form finish quality of concrete. It is almost impossible to obtain Class 1 surface finish as prescribed in AS 3610.1 using any formwork plywood product.

Bond Types

Type A bond and type B bond is used for F17 formply manufacture. Most products on the market use type A bond with E0 formaldehyde emission. The type A bond is phenolic glue and it makes sure the veneers are glued permanently.

Type C bond is urea-formaldehyde. It is also permitted by the formwork plywood standard but not accepted by most construction companies.

Film Types

Formply can use different coatings or films however the most common film is paper impregnated with phenolic adhesive (A-bond). During the manufacturing process, the adhesive cure on the panel surface to produce the typical plastic film seen on most formply. It is usually black in color for the Australia market.

Certified F17 Companies

As of May 2020, there are quite a dozen companies certified with AS 6669 globally. The number doesn’t include the factories that were not registered with JAS-ANZ. These manufacturers are from Australia, Malaysia, China, Papua New Guinea, and New Zealand. Each of them cater to different customers with their products in various quality range.


F17 Formply Certification Body

· Engineered Wood Products Association of Australasia Limited also trading as Engineered Wood     Products Association Pty Ltd (EWPA)

· Bureau Veritas Australia Pty. Ltd.

· SAI Global Certification Services Pty Ltd Trading as SAI Global

· BSI Group (Australia and New Zealand) Pty Ltd

· CertMark International Pty Ltd

Buy F17 Formply From China?

We are the most complete supplier and manufacturer contact of the f17 grade plywood. If you are looking to buy benchmark certified F17 formwork plywood from China, contact us for more details.

Use Formply With Care

It is important for users to store and protect the formply well. Each pallet must be placed on balanced support. If the formply is used outdoor, there should be a cover for sunshine and rain.

It is good practice to oil each panel before put in place. And clean the phenolic film face after each use.

Product Details:

 BRAND NAME CAMEL-PLY
 SIZE
 1200 x 1800; 1200 × 2400mm
 GLUE
 Phenolic W.B.P Glue
 FILM Dynea Brown/Black Film
 CORE Eucalyptus
 THICKNESS 17mm
 THICKNESS TOLERANCE 0.2/0.5mm
KEY PROCESSINGTwo Times Hot-Press & Two Times Sanding
 USING TIMES 30~40 Times
CERTIFICATE CE; FCS; ISO 9001; AS6669.


Manufacturing Process:

1.Veneer Storing2.Veneer Grading3.Veneer Edge Sanding4.Veneer Jointing5.Veneer Drying6.Veneer Gluing7.Lay-up Baseboard





8.Cold-Pressing
9.Repair Baseboard10.Hot-Pressing11.First Time Putty12.Sanding13.Cutting14.Edge Selling

15.Samples Testing16.Light Sanding17.Film Coating18. Q.C selecting 19.Edge Sealing20.Product Storing21.Loading




  • SIZE:1200×1800/1200×2400mm
  • CORE:Eucalyptus
  • GLUE:A Bond/Phenolic W.B.P E0 Glue
  • FILM:Dynea Brwon/Black Film
  • PROCESSING:Three Times Hot-Press & Two Times Sanding
  • THICKNESS TOLERANCE:0.5mm
  • CERTIFICATE:AS/NZS2269 & AS6669 & FSC & ISO 9001
  • USAGE:Shuttering/Concrete Formwork
F17 FORMPLY
CAMEL FORMPLY has been manufactured at our plant in China,for in excess of 15 years and has been used successfully in the Asia Australia and New Zealand.
CAMEL FORMPLY resists dilute acids and alkalines which increases the number of uses that is obtained when used with concrete.
CAMEL FORMPLY surface is very smooth which transmits into the finish of the concrete.
