MESH ANTI-SLIP PLY

A durable, anti-slip hardwood plywood designed to sustain heavy duty usage resulting in low wear and tear over its course of life. Through specialty manufacturing process the high quality plywood board is coated with a hard wearing film overlay hot pressed into a hexagonal shape to boost its anti-slip properties. Camelply's Hexa is also available as fire-retardant composite board for specialty applications.

SIZE： 375～3050mm
FACE： Hexa/Wire/Mesh/Rice pattern
BACK： Dynea Black/Brown film
CORE： Russian Birch/ Baltic Birch/ Eucalyptus/ Poplar/Combi
GLUE： Phenolic Resin Glue,EN314-2 Class-3, BFU100, WBP Grade, A Bond
PROCESSING： THREE TIMES HOT-PRESS & TWO TIMES SANDING
EDGE SEALING： Acrylic water-based paint
THICKNESS TOLERANCE： 0.2~0.5 mm accordinng to ragne of thickness
USAGE： Platforms/Scaffoldings/Transportation industry/Playgrounds

Parameters

SIZE： 375～3050mm
FACE： Hexa/Wire/Mesh/Rice pattern
BACK： Dynea Black/Brown film
CORE： Russian Birch/ Baltic Birch/ Eucalyptus/ Poplar/Combi
GLUE： Phenolic Resin Glue,EN314-2 Class-3, BFU100, WBP Grade, A Bond
PROCESSING： THREE TIMES HOT-PRESS & TWO TIMES SANDING
EDGE SEALING： Acrylic water-based paint
THICKNESS TOLERANCE： 0.2~0.5 mm accordinng to ragne of thickness
USAGE： Platforms/Scaffoldings/Transportation industry/Playgrounds

Product Detail

Product Details:

BRAND NAME	CAMELPLY
FACE	Hexa/Wire/Mesh/Rice pattern
BACK	Dynea Black/Brown film
SIZE	375~3050mm
GLUE	Phenolic WBP Glue
CORE	Russian Birch/ Baltic Birch/ Eucalyptus/Combi
THICKNESS TOLERANCE	0.2～0.5mm
KEY PROCESSING	Three Times Hot-Press & Two Times Sanding
USING TIMES	Platform/Scaffolding/Transportation/Playground
CERTIFICATE	CE; FCS; ISO 9001; AS6669.

Manufacturing Process:

1.Veneer Storing	2.Veneer Grading	3.Veneer Edge Sanding	4.Veneer Jointing	5.Veneer Drying	6.Veneer Gluing	7.Lay-up Baseboard

8.Cold-Pressing	9.Repair Baseboard	10.Hot-Pressing	11.First Time Putty	12.Sanding	13.Cutting	14.Edge Selling

15.Samples Testing	16.Light Sanding	17.Film Coating	18. Q.C selecting	19.Edge Sealing	20.Product Storing	21.Loading
